Details

"Race bred". It's not just a slogan printed on the SB150 top tube. We've been pinning on numbers and pinning the throttle since 1985.

Geometry Chart:
SIZE	SMALL	MEDIUM	LARGE	X-LARGE
A SEAT TUBE LENGTH (mm)	380	410	450	495
B TOPTUBE LENGTH (mm)	571.9	602.4	625.6	653.9
C HEADTUBE ANGLE	64.5	64.5	64.5	64.5
D EFF. SEAT TUBE ANGLE	77	77	76.9	76.8
E CHAINSTAY LENGTH (mm)	433	433	433	433
F WHEELBASE (mm)	1192.5	1223.2	1248	1277.7
G ESTIMATED BB HEIGHT (mm)	347.8	347.8	347.9	347.9
H STANDOVER (mm)	720.6	727.8	740.8	761.6
I HEADTUBE LENGTH (mm)	95	96.6	107.7	118.8
J AXLE TO CROWN (mm)	577.1	577.1	577.1	577.1
K OFFSET (mm)	44	44	44	44
L STACK (mm)	613.4	614.8	624.8	634.8
M REACH (mm)	430.2	460.2	480.2	505.2
N FRONT CENTER (mm)	759.5	790.2	815	844.7

Specs

Frame	C/Series carbon fiber frame, Switch Infinity suspension technology, press-fit BB92, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, integrated derailleur hanger, and axle.
Fork	Select from dropdown above
Rear Shock	Select from dropdown above
Wheels	DT SWISS E1900 30MM *Orders may ship with DT SWISS E532 30MM
Tires	Front: MAXXIS ASSEGAI 2.5 EXO+ Rear: MAXXIS MINION DHR II 2.4 EXO+
Bottom Bracket	SRAM DUB BB92
Crankset	SRAM GX EAGLE 30T 170MM
Shifters	SRAM GX EAGLE
Rear Derailleur	SRAM GX EAGLE
Cassette/Freewheel	SRAM GX EAGLE 1275 10-52
Chain	SRAM GX EAGLE
Brakes	SRAM CODE R
Rotors	SRAM CENTERLINE 200/SRAM CENTERLINE 200
Handlebars	RACE FACE AEFFECT R 35X780MM
Tape/Grips	ODI ELITE PRO
Stem	RACE FACE RIDE 35X50MM
Headset	CANE CREEK 40 INTEGRATED
Seatpost	FOX TRANSFER 31.6MM / SM: 125MM, MD: 150MM, LG/XL: 175MM
Saddle	SILVERADO CUSTOM

* Subject to change without notice.

Option	MPN	Store SKU
Turquoise / Fox Performance Suspension / Large	B22150CLGPTUP2C028700	210000081348
Turquoise / Fox Performance Suspension / X-Large	B22150CXLPTUP2C028700	210000081349
