Orbea MX 40

Orbea MX 40
$799.00
Color:
Red/Black
Please select options

Details

Technologically speaking, MX bikes are especially innovative and versatile. The AL6061 frame tubing of the MX is carefully shaped and manipulated to put strength where it’s needed without unnecessary weight. Internal Cable Routing not only gives a cleaner appearance, but also takes advantage of full-length cable housing for great performance with lower maintenance.

Most importantly, though, MX is compatible with your riding style. The patented Orbea Digit quick-adjust seat post fits perfectly, and mounting points for racks make increasing carrying capacity a breeze. The sealed headset and BB bearings, replaceable derailleur hanger, and powerful hydraulic disc brakes add up to a bike that is durable, reliable, and flat-out performs. All MX bikes are painted and assembled in the EU and come with the Orbea Lifetime Warranty.

Specs

Frame Orbea MX Alloy only disc
Fork SR Suntour XCT 30 Coil 100mm QR
Headset VP-Z104PD 1-1/8" Semi-Cartridge
Rims/Wheels Orbea Black Rock 23c Disc
Tires Kenda K1153 2.35" 30TPI
Crankset Alloy forged 22x36t 9S
Chain Shimano HG53 9-Speed
Front Derailleur Shimano M2020 31.8mm
Rear Derailleur Shimano Alivio M3100 SGS Shadow
Rear Cogs Sun Race CSM989 11-36t 9-Speed
Shifters Shimano Alivio SL-M3100
Handlebars Alloy Flat 31.8mm 720mm
Stem Alloy 31.8mm interface 7º
Brakes Shimano MT200 Hydraulic Disc
Saddle Selle Royal 2058 DRN
Seat Post Alloy 27.2 Offset 0

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Red/Black / Small 8434446744754 L20115NT 210000068174
Red/Black / Medium 8434446744792 L20117NT 210000068175
