Details
TAKE BACK YOUR WILD
It's time to get moving. Load up your pack for an afternoon ride and start pedaling. Whatever obstacles exist between you and the trails and your Special Places, it's time to run over them. Reclaim access and discover new adventures the way you like – aboard a fun and capable machine that enhances your skills while it extends your range. Conquer steep climbs and push the limits of traction and good judgment on the way back down. Enjoy clever design and sophisticated suspension kinematics, or simply focus on the trail. Wild FS revitalizes your riding and helps you chart new destinations. Take back control – Take back your Wild.
GEOMETRY
The new Wild FS geometry is designed to give new riders more comfort and stability - and for more experienced riders - a bike that doesn't hold them back no matter the terrain.
- Slacker Head Angle: Great Stability
- Lower Bottom Bracket: Corners Naturally
- Longer Cockpit: Room To Move While Maintaining Balance
- Longer Wheel Base: Stability At High Speeds
- Steep Seat Angle: Proper Pedaling Position
- Short Seat Tube: For Long Dropper Posts
KINEMATICS
160MM TRAVEL
Some riders use them to climb thousands of meters on huge rides, others weave in and out of bike parks and jumps during their daily adventures. Wild FS is designed to be flexible and accommodate your style.
PROGRESSIVE
Great tuning capability and a progressive leverage rate help suspension ride higher and recover faster. More progression at full travel limits bottom out forces to frame, suspension and rider.
ANTI-SQUAT
The main pivot point on the Wild FS is located to work efficiently with single-ring setups and adapted for the greater BB drop associated with 29" wheels. The balance between compliance and efficiency makes for suspension with a huge range of capability.
VERTICAL SHOCK
Clearance and compact design. Wild FS uses a vertical shock mounting position, with the goal of fitting an additional battery while maintaining low standover.
MODULAR CAPACITY SOLUTION
2PAK
Wild FS is ready for a second battery that extends your range up to a massive 1125 Watt Hours, depending on the model.
BOTTLE CAGE
Wild FS is compatible with a standard bottle and many cage-mount tool solutions.
BATTERY COVER
A proprietary cover of Carbon or technical polymer protects the battery with a simple and reliable locking dial.
COMPUTER MOUNT
Our unique mount allows three different mounting positions so the display is in the position you prefer.
KEY HOLDER
The perfect place to store your battery key - no more searching your pockets and backpack.
BLOCKLOCK HEADSET / MOTOR CAGE
BLOCKLOCK HEADSET
The Acros Blocklock headset protects Wild FS by preventing the fork crown from impacting the frame during mishaps.
MOTOR CAGE
The lower injection-moulded engine protector is extremely rugged without the weight of metal. Perfect protection from unexpected rocks and ledges.
OVERSIZED PIVOT
The swing link rotates on an oversized spindle that gives a major increase in stiffness over smaller axle designs.
SIZE | SMALL/MEDIUM | LARGE | X-LARGE |
---|---|---|---|
1 - SEAT TUBE (C-T) (mm) | 406 | 444 | 483 |
2 - TOP TUBE (EFF) (mm) | 585 | 612 | 645 |
3 - HEAD TUBE (mm) | 100 | 110 | 125 |
4 - CHAINSTAY (mm) | 455 | ||
5 - BB HEIGHT (mm) | 345 | ||
6 - BB DROP (mm) | 30 | ||
7 - WHEELBASE (mm) | 1203 | 1232 | 1268 |
8 - HEAD ANGLE | 65.5° | ||
9 - SEAT ANGLE | 76° | ||
10 - STANDOVER (mm) | 725 | 740 | 765 |
11 - REACH (mm) | 430 | 455 | 485 |
12 - STACK (mm) | 621 | 630 | 644 |
13 - FORK LENGTH (mm) | 570 | ||
RAKE (mm) | 44 |
HEIGHT ( CM ) | HEIGHT ( IN ) | SIZE |
---|---|---|
160-175 | 63.0"-68.9" | SMALL/MEDIUM |
170-185 | 66.9"-72.8" | LARGE |
180-198 | 70.9"-78.0" | X-LARGE |
* Estimated measurements |
SIZE | CRANK | STEM | HANDLEBAR | DROPPER SEATPOST |
---|---|---|---|---|
SMALL/MEDIUM | 160 | 40 | 780 | 390/125 |
LARGE | 160 | 50 | 780 | 440/150 |
X-LARGE | 160 | 50 | 780 | 480/170 |
* The handlebar size is center-center |
Due to supply-chain issues, Specs are subject to change without notice.
Specs
Frame |
ORBEA WILD Full Suspension 2021 Carbon 160mm Travel FRONT TRIANGLE: Carbon REAR TRIANGLE: Carbon, FiberLink BATTERY COVER: Carbon, Boost 12x148 Bosch Gen4 |
---|---|
Fork | Fox 38 Float Performance 160 Grip 3-Position QR15x110 E-Bike Optimized |
Rear Shock | Fox Float DPS Performance Trunnion 3-Position Evol LV custom tune 205x65mm |
Wheels | DT Swiss H-1900 Spline 30c TLR 15/110mm 6-Bolt |
Tires |
Maxxis Minion DHF 2.60" 120 TPI FB 3C Maxx Terra Exo+ TR Maxxis Minion DHR II 2.60" 120 TPI FB 3C Maxx Terra Exo+ TR |
Crankset | e*thirteen Plus Alu |
Chainrings | PW-NW32-G4 |
Shifters | Shimano SLX M7100 I-Spec EV |
Rear Derailleur | Shimano XT M8100 SGS Shadow Plus |
Cassette/Freewheel | Shimano CS-M7100 10-51T 12-Speed |
Chain | ING PW-NW32-G4 |
Brakes | Shimano XT M8120 Hydraulic Disc |
Handlebars | Race Face Aeffect 35 20mm Rise 780mm |
Stem | Race Face Aeffect R 35mm interface |
Headset | OC Key Holder |
Seatpost | OC MC20 Mountain Control Dropper, 31.6mm |
Saddle | Fizik Aidon 208x145mm manganese rail |
Pedals | Sold separately |
Accessories & Extras | Abus battery powertube lock PLUS |
Motor | BOSCH Performance CX Cruise (20mph) BDU480CX |
Battery | BOSCH Powertube 625Wh Horizontal US BBP295 |
Controller/Display | BOSCH Display unit KIOX Black BUI330 |
Charger | Compact Charger 2A (100-240V) Worldwide |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Red Wine/Carbon / X-Large | 08434446906084 | M65119VS | 210000084488 |
